Antigravity MN8014 KV100 180 T-Motor Multi-Rotor Fixed Wing Efficient Brushless Motors And Lightweight Design.

Name: Antigravity MN8014 KV100 180 TMotor MultiRotor Fixed Wing Efficient Brushless Motors And Lightweight Design
Brand: T-MOTOR
Price: 239.90 USD

Buy cheap Antigravity MN8014 KV100 180 T-Motor Multi-Rotor Fixed Wing Efficient Brushless Motors And Lightweight Design. product

Material : Metal

private mold : Yes

Magnet Level : 180°C high temperature resistance

Lead : 14AWG*90mm

compatible brand : T-MOTOR

Rotor Dynamic Balance Standard : ≤15Mg

Bearing : Imported 6901ZZ

Coil Insulation Test : 1000V/5s

Configuration : 36N42P

Shaft Diameter : IN:12mm

Copper Wire : 220°C high temperature resistance

Stator : Anti-rust treatment; 180°Chigh temperature-resisti

Price : $239.90-279.90 / piece

Brand Name : T-MOTOR

MOQ : 1 piece

Place of Origin : China, Jiangxi China

Contact Now

Product Features
Magnet Level	180°C high temperature resistance
Configuration	36N42P
Stator	Anti-rust treatment; 180°Chigh temperature-resisting coatings
Shaft Diameter	IN:12mm
Material	Metal
place of origin	Jiangxi, China
Bearing	Imported 6901ZZ
Coil Insulation Test	1000V/5s
brand name	T-MOTOR
Lead	14AWG*90mm
private mold	Yes
Rotor Dynamic Balance Standard	≤15Mg
Copper Wire	220°C high temperature resistance
Motor Size	Phi 87.8*31.5mm

About T-MOTOR MN8014 Multirotor VTOL UAV Motor KV100

T-Motor Antigravity MN8014 KV100 Brushless Motor is designed to deliver exceptional power and reliability for professional UAVs, including multi-rotors and VTOL applications. With a maximum thrust of 13.9kg and a power ratio of 35, this motor provides the perfect balance of performance and durability, ensuring smooth, stable flights even under heavy loads.

Antigravity MN8014 Highlights:

Ultra light, high efficiency
Max.Thrust:13.9kg, Motor Weight:439g, Power Ratio:35
Employment of 15mm aluminium shaft and 24mm big bearing for stability improvement and service life extension.
Motor service life: 800 hours
Self-circulating cooling system, high-temperature-resistant wires and arc magnets help release all potential for high efficiency.
Imported bearings and high strength 7075 aviation aluminium alloy for long motor endurance.

" Antigravity Series" motors are an ultra-light zero gravity for Multi-rotor motor.
High-Qualityimported Materials; High Slot Space Factor On Winding For Longer, Clearer And More Stable Flight.

Application Areas:

Multi-rotors, VTOL,UAVs,Heavy-duty professional drones

Packing List Includes:

1 x T-MOTOR MN8014 Motor KV100( kv which you choose)

1 x Hardware pack

Matching Guide:

T-MOTOR Propeller G29*9.5 / G30*10.5 / FLAME 80A 12S V2.0 ESC

Test Item	MN8014
KV	100
Idle Current (24V)	1.4A
Peak Current (180s)	52A
Max. Power (180s)	2423W
Rated Voltage (Lipo)	12S
Internal Resistance	65m R
Weight (Incl. Cable)	392g
Package Weight	602g
